In this tutorial, we take a deep dive into the capabilities of Zarr, a library designed for efficient storage & manipulation of large, multidimensional arrays. We begin by exploring the basics, creating arrays, setting chunking strategies, and modifying values directly on disk. From there, we expand into more advanced operations such as experimenting with chunk sizes for different access patterns, applying multiple compression codecs to optimize both speed and storage efficiency, and comparing their performance on synthetic datasets. We also build hierarchical structures enriched with metadata, simulate realistic workflows with time-series and volumetric data, and demonstrate advanced indexing to extract meaningful subsets. Check out the FULL CODES here.
!pip install zarr numcodecs -q
import zarr
import numpy as np
import matplotlib.pyplot as plt
from numcodecs import Blosc, Delta, FixedScaleOffset
import tempfile
import shutil
import os
from pathlib import Path
print(f"Zarr version: {zarr.__version__}")
print(f"NumPy version: {np.__version__}")
print("=== BASIC ZARR OPERATIONS ===")We begin our tutorial by installing Zarr and Numcodecs, along with essential libraries like NumPy and Matplotlib. We then set up the environment and verify the versions, preparing ourselves to dive into basic Zarr operations. Check out the FULL CODES here.
tutorial_dir = Path(tempfile.mkdtemp(prefix="zarr_tutorial_"))
print(f"Working directory: {tutorial_dir}")
z1 = zarr.zeros((1000, 1000), chunks=(100, 100), dtype="f4",
store=str(tutorial_dir / 'basic_array.zarr'), zarr_format=2)
z2 = zarr.ones((500, 500, 10), chunks=(100, 100, 5), dtype="i4",
store=str(tutorial_dir / 'multi_dim.zarr'), zarr_format=2)
print(f"2D Array shape: {z1.shape}, chunks: {z1.chunks}, dtype: {z1.dtype}")
print(f"3D Array shape: {z2.shape}, chunks: {z2.chunks}, dtype: {z2.dtype}")
z1[100:200, 100:200] = np.random.random((100, 100)).astype('f4')
z2[:, :, 0] = np.arange(500*500).reshape(500, 500)
print(f"Memory usage estimate: {z1.nbytes_stored() / 1024**2:.2f} MB")We create our working directory and initialize Zarr arrays: a 2D array of zeros and a 3D array of ones. We then fill them with random and sequential values, while also checking their shapes, chunk sizes, and memory usage in real time. Check out the FULL CODES here.
print("\n=== ADVANCED CHUNKING ===")
time_steps, height, width = 365, 1000, 2000
time_series = zarr.zeros(
(time_steps, height, width),
chunks=(30, 250, 500),
dtype="f4",
store=str(tutorial_dir / 'time_series.zarr'),
zarr_format=2
)
for t in range(0, time_steps, 30):
end_t = min(t + 30, time_steps)
seasonal = np.sin(2 * np.pi * np.arange(t, end_t) / 365)[:, None, None]
spatial = np.random.normal(20, 5, (end_t - t, height, width))
time_series[t:end_t] = (spatial + 10 * seasonal).astype('f4')
print(f"Time series created: {time_series.shape}")
print(f"Approximate chunks created")
import time
start = time.time()
temporal_slice = time_series[:, 500, 1000]
temporal_time = time.time() - start
start = time.time()
spatial_slice = time_series[100, :200, :200]
spatial_time = time.time() - start
print(f"Temporal access time: {temporal_time:.4f}s")
print(f"Spatial access time: {spatial_time:.4f}s")In this step, we simulate a year-long time-series dataset with optimized chunking for both temporal and spatial access. We add seasonal patterns and spatial noise, then measure access speeds, allowing us to see firsthand how chunking impacts performance in real-world data exploration. Check out the FULL CODES here.
print("\n=== COMPRESSION AND CODECS ===")
data = np.random.randint(0, 1000, (1000, 1000), dtype="i4")
from zarr.codecs import BloscCodec, BytesCodec
z_none = zarr.array(data, chunks=(100, 100),
codecs=[BytesCodec()],
store=str(tutorial_dir / 'no_compress.zarr'))
z_lz4 = zarr.array(data, chunks=(100, 100),
codecs=[BytesCodec(), BloscCodec(cname="lz4", clevel=5)],
store=str(tutorial_dir / 'lz4_compress.zarr'))
z_zstd = zarr.array(data, chunks=(100, 100),
codecs=[BytesCodec(), BloscCodec(cname="zstd", clevel=9)],
store=str(tutorial_dir / 'zstd_compress.zarr'))
sequential_data = np.cumsum(np.random.randint(-5, 6, (1000, 1000)), axis=1)
z_delta = zarr.array(sequential_data, chunks=(100, 100),
codecs=[BytesCodec(), BloscCodec(cname="zstd", clevel=5)],
store=str(tutorial_dir / 'sequential_compress.zarr'))
sizes = {
'No compression': z_none.nbytes_stored(),
'LZ4': z_lz4.nbytes_stored(),
'ZSTD': z_zstd.nbytes_stored(),
'Sequential+ZSTD': z_delta.nbytes_stored()
}
print("Compression comparison:")
original_size = data.nbytes
for name, size in sizes.items():
ratio = size / original_size
print(f"{name}: {size/1024**2:.2f} MB (ratio: {ratio:.3f})")
print("\n=== HIERARCHICAL DATA ORGANIZATION ===")
root = zarr.open_group(str(tutorial_dir / 'experiment.zarr'), mode="w")
raw_data = root.create_group('raw_data')
processed = root.create_group('processed')
metadata = root.create_group('metadata')
raw_data.create_dataset('images', shape=(100, 512, 512), chunks=(10, 128, 128), dtype="u2")
raw_data.create_dataset('timestamps', shape=(100,), dtype="datetime64[ns]")
processed.create_dataset('normalized', shape=(100, 512, 512), chunks=(10, 128, 128), dtype="f4")
processed.create_dataset('features', shape=(100, 50), chunks=(20, 50), dtype="f4")
root.attrs['experiment_id'] = 'EXP_2024_001'
root.attrs['description'] = 'Advanced Zarr tutorial demonstration'
root.attrs['created'] = str(np.datetime64('2024-01-01'))
raw_data.attrs['instrument'] = 'Synthetic Camera'
raw_data.attrs['resolution'] = [512, 512]
processed.attrs['normalization'] = 'z-score'
timestamps = np.datetime64('2024-01-01') + np.arange(100) * np.timedelta64(1, 'h')
raw_data['timestamps'][:] = timestamps
for i in range(100):
frame = np.random.poisson(100 + 50 * np.sin(2 * np.pi * i / 100), (512, 512)).astype('u2')
raw_data['images'][i] = frame
print(f"Created hierarchical structure with {len(list(root.group_keys()))} groups")
print(f"Data arrays and groups created successfully")
print("\n=== ADVANCED INDEXING ===")
volume_data = zarr.zeros((50, 20, 256, 256), chunks=(5, 5, 64, 64), dtype="f4",
store=str(tutorial_dir / 'volume.zarr'), zarr_format=2)
for t in range(50):
for z in range(20):
y, x = np.ogrid[:256, :256]
center_y, center_x = 128 + 20*np.sin(t*0.1), 128 + 20*np.cos(t*0.1)
focus_quality = 1 - abs(z - 10) / 10
signal = focus_quality * np.exp(-((y-center_y)**2 + (x-center_x)**2) / (50**2))
noise = 0.1 * np.random.random((256, 256))
volume_data[t, z] = (signal + noise).astype('f4')
print("Various slicing operations:")
max_projection = np.max(volume_data[:, 10], axis=0)
print(f"Max projection shape: {max_projection.shape}")
z_stack = volume_data[25, :, 100:156, 100:156]
print(f"Z-stack subset: {z_stack.shape}")
bright_pixels = volume_data[volume_data > 0.5]
print(f"Pixels above threshold: {len(bright_pixels)}")We benchmark compression by writing the same data with no compression, LZ4, and ZSTD, then compare on-disk sizes to see practical savings. Next, we organize an experiment as a Zarr group hierarchy with rich attributes, images, and timestamps. Finally, we generate a synthetic 4D volume and perform advanced indexing, max projections, sub-stacks, and thresholding, to validate fast, slice-wise access. Check out the FULL CODES here.
print("\n=== PERFORMANCE OPTIMIZATION ===")
def process_chunk_serial(data, func):
results = []
for i in range(0, len(dt), 100):
chunk = data[i:i+100]
results.append(func(chunk))
return np.concatenate(results)
def gaussian_filter_1d(x, sigma=1.0):
kernel_size = int(4 * sigma)
if kernel_size % 2 == 0:
kernel_size += 1
kernel = np.exp(-0.5 * ((np.arange(kernel_size) - kernel_size//2) / sigma)**2)
kernel = kernel / kernel.sum()
return np.convolve(x.astype(float), kernel, mode="same")
large_array = zarr.random.random((10000,), chunks=(1000,),
store=str(tutorial_dir / 'large.zarr'), zarr_format=2)
start_time = time.time()
chunk_size = 1000
filtered_data = []
for i in range(0, len(large_array), chunk_size):
end_idx = min(i + chunk_size, len(large_array))
chunk_data = large_array[i:end_idx]
smoothed = np.convolve(chunk_data, np.ones(5)/5, mode="same")
filtered_data.append(smoothed)
result = np.concatenate(filtered_data)
processing_time = time.time() - start_time
print(f"Chunk-aware processing time: {processing_time:.4f}s")
print(f"Processed {len(large_array):,} elements")
print("\n=== VISUALIZATION ===")
fig, axes = plt.subplots(2, 3, figsize=(15, 10))
fig.suptitle('Advanced Zarr Tutorial - Data Visualization', fontsize=16)
axes[0,0].plot(temporal_slice)
axes[0,0].set_title('Temporal Evolution (Single Pixel)')
axes[0,0].set_xlabel('Day of Year')
axes[0,0].set_ylabel('Temperature')
im1 = axes[0,1].imshow(spatial_slice, cmap='viridis')
axes[0,1].set_title('Spatial Pattern (Day 100)')
plt.colorbar(im1, ax=axes[0,1])
methods = list(sizes.keys())
ratios = [sizes[m]/original_size for m in methods]
axes[0,2].bar(range(len(methods)), ratios)
axes[0,2].set_xticks(range(len(methods)))
axes[0,2].set_xticklabels(methods, rotation=45)
axes[0,2].set_title('Compression Ratios')
axes[0,2].set_ylabel('Size Ratio')
axes[1,0].imshow(max_projection, cmap='hot')
axes[1,0].set_title('Max Intensity Projection')
z_profile = np.mean(volume_data[25, :, 120:136, 120:136], axis=(1,2))
axes[1,1].plot(z_profile, 'o-')
axes[1,1].set_title('Z-Profile (Center Region)')
axes[1,1].set_xlabel('Z-slice')
axes[1,1].set_ylabel('Mean Intensity')
axes[1,2].plot(result[:1000])
axes[1,2].set_title('Processed Signal (First 1000 points)')
axes[1,2].set_xlabel('Sample')
axes[1,2].set_ylabel('Amplitude')
plt.tight_layout()
plt.show()We optimize performance by processing data in chunk-sized batches, applying simple smoothing filters without loading everything into memory. We then visualize temporal trends, spatial patterns, compression effects, and volume profiles, allowing us to see at a glance how our choices in chunking and compression shape the results. Check out the FULL CODES here.
print("\n=== TUTORIAL SUMMARY ===")
print("Zarr features demonstrated:")
print("✓ Multi-dimensional array creation and manipulation")
print("✓ Optimal chunking strategies for different access patterns")
print("✓ Advanced compression with multiple codecs")
print("✓ Hierarchical data organization with metadata")
print("✓ Advanced indexing and data views")
print("✓ Performance optimization techniques")
print("✓ Integration with visualization tools")
def show_tree(path, prefix="", max_depth=3, current_depth=0):
if current_depth > max_depth:
return
items = sorted(path.iterdir())
for i, item in enumerate(items):
is_last = i == len(items) - 1
current_prefix = "└── " if is_last else "├── "
print(f"{prefix}{current_prefix}{item.name}")
if item.is_dir() and current_depth We wrap up the tutorial by highlighting everything we explored: array creation, chunking, compression, hierarchical organization, indexing, performance tuning, and visualization. We also review the files generated during the session and confirm total disk usage, giving us a complete picture of how Zarr handles large-scale data efficiently from start to finish.
In conclusion, we move beyond the fundamentals and gain a comprehensive view of how Zarr fits into modern data workflows. We see how it handles storage optimization through compression, organizes complex experiments through hierarchical groups, and enables smooth access to slices of large datasets with minimal overhead. Performance enhancements, such as chunk-aware processing and integration with visualization tools, bring additional depth, demonstrating how theory is directly translated into practice.
