In this tutorial, we explore how exploration strategies shape intelligent decision-making through agent-based problem solving. We build and train three agents, Q-Learning with epsilon-greedy exploration, Upper Confidence Bound (UCB), and Monte Carlo Tree Search (MCTS), to navigate a grid world and reach a goal efficiently while avoiding obstacles. Also, we experiment with different ways of balancing exploration and exploitation, visualize learning curves, and compare how each agent adapts and performs under uncertainty. Check out the FULL CODES here.
import numpy as np
import random
from collections import defaultdict, deque
import math
import matplotlib.pyplot as plt
from typing import List, Tuple, Dict
class GridWorld:
def __init__(self, size=10, n_obstacles=15):
self.size = size
self.grid = np.zeros((size, size))
self.start = (0, 0)
self.goal = (size-1, size-1)
obstacles = set()
while len(obstacles) We begin by creating a grid world environment that challenges our agent to reach a goal while avoiding obstacles. We design its structure, define movement rules, and ensure realistic navigation boundaries to simulate an interactive problem-solving space. This forms the foundation where our exploration agents will operate and learn. Check out the FULL CODES here.
class QLearningAgent:
def __init__(self, n_actions=4, alpha=0.1, gamma=0.95, epsilon=1.0):
self.n_actions = n_actions
self.alpha = alpha
self.gamma = gamma
self.epsilon = epsilon
self.q_table = defaultdict(lambda: np.zeros(n_actions))
def get_action(self, state, valid_actions):
if random.random() We implement the Q-Learning agent that learns through experience, guided by an epsilon-greedy policy. We observe how it explores random actions early on and gradually focuses on the most rewarding paths. Through iterative updates, it learns to balance exploration and exploitation effectively.
class UCBAgent:
def __init__(self, n_actions=4, c=2.0, gamma=0.95):
self.n_actions = n_actions
self.c = c
self.gamma = gamma
self.q_values = defaultdict(lambda: np.zeros(n_actions))
self.action_counts = defaultdict(lambda: np.zeros(n_actions))
self.total_counts = defaultdict(int)
def get_action(self, state, valid_actions):
self.total_counts[state] += 1
ucb_values = []
for action in valid_actions:
q = self.q_values[state][action]
count = self.action_counts[state][action]
if count == 0:
return action
exploration_bonus = self.c * math.sqrt(math.log(self.total_counts[state]) / count)
ucb_values.append((action, q + exploration_bonus))
return max(ucb_values, key=lambda x: x[1])[0]
def update(self, state, action, reward, next_state, valid_next_actions):
self.action_counts[state][action] += 1
count = self.action_counts[state][action]
current_q = self.q_values[state][action]
if valid_next_actions:
max_next_q = max([self.q_values[next_state][a] for a in valid_next_actions])
else:
max_next_q = 0
target = reward + self.gamma * max_next_q
self.q_values[state][action] += (target - current_q) / countWe develop the UCB agent that uses confidence bounds to guide its exploration decisions. We watch how it strategically tries less-visited actions while prioritizing those that yield higher rewards. This approach helps us understand a more mathematically grounded exploration strategy. Check out the FULL CODES here.
class MCTSNode:
def __init__(self, state, parent=None):
self.state = state
self.parent = parent
self.children = {}
self.visits = 0
self.value = 0.0
def is_fully_expanded(self, valid_actions):
return len(self.children) == len(valid_actions)
def best_child(self, c=1.4):
choices = [(action, child.value / child.visits +
c * math.sqrt(2 * math.log(self.visits) / child.visits))
for action, child in self.children.items()]
return max(choices, key=lambda x: x[1])
class MCTSAgent:
def __init__(self, env, n_simulations=50):
self.env = env
self.n_simulations = n_simulations
def search(self, state):
root = MCTSNode(state)
for _ in range(self.n_simulations):
node = root
sim_env = GridWorld(size=self.env.size)
sim_env.grid = self.env.grid.copy()
sim_env.agent_pos = state
while node.is_fully_expanded(sim_env.get_valid_actions(node.state)) and node.children:
action, _ = node.best_child()
node = node.children[action]
sim_env.agent_pos = node.state
valid_actions = sim_env.get_valid_actions(node.state)
if valid_actions and not node.is_fully_expanded(valid_actions):
untried = [a for a in valid_actions if a not in node.children]
action = random.choice(untried)
next_state, _, _ = sim_env.step(action)
child = MCTSNode(next_state, parent=node)
node.children[action] = child
node = child
total_reward = 0
depth = 0
while depth We construct the Monte Carlo Tree Search (MCTS) agent to simulate and plan multiple potential future outcomes. We see how it builds a search tree, expands promising branches, and backpropagates results to refine decisions. This allows the agent to plan intelligently before acting. Check out the FULL CODES here.
def train_agent(agent, env, episodes=500, max_steps=100, agent_type="standard"):
rewards_history = []
for episode in range(episodes):
state = env.reset()
total_reward = 0
for step in range(max_steps):
valid_actions = env.get_valid_actions(state)
if agent_type == "mcts":
action = agent.search(state)
else:
action = agent.get_action(state, valid_actions)
next_state, reward, done = env.step(action)
total_reward += reward
if agent_type != "mcts":
valid_next = env.get_valid_actions(next_state)
agent.update(state, action, reward, next_state, valid_next)
state = next_state
if done:
break
rewards_history.append(total_reward)
if hasattr(agent, 'decay_epsilon'):
agent.decay_epsilon()
if (episode + 1) % 100 == 0:
avg_reward = np.mean(rewards_history[-100:])
print(f"Episode {episode+1}/{episodes}, Avg Reward: {avg_reward:.2f}")
return rewards_history
if __name__ == "__main__":
print("=" * 70)
print("Problem Solving via Exploration Agents Tutorial")
print("=" * 70)
env = GridWorld(size=8, n_obstacles=10)
agents_config = {
'Q-Learning (ε-greedy)': (QLearningAgent(), 'standard'),
'UCB Agent': (UCBAgent(), 'standard'),
'MCTS Agent': (MCTSAgent(env, n_simulations=30), 'mcts')
}
results = {}
for name, (agent, agent_type) in agents_config.items():
print(f"\nTraining {name}...")
rewards = train_agent(agent, GridWorld(size=8, n_obstacles=10),
episodes=300, agent_type=agent_type)
results[name] = rewards
plt.figure(figsize=(12, 5))
plt.subplot(1, 2, 1)
for name, rewards in results.items():
smoothed = np.convolve(rewards, np.ones(20)/20, mode="valid")
plt.plot(smoothed, label=name, linewidth=2)
plt.xlabel('Episode')
plt.ylabel('Reward (smoothed)')
plt.title('Agent Performance Comparison')
plt.legend()
plt.grid(alpha=0.3)
plt.subplot(1, 2, 2)
for name, rewards in results.items():
avg_last_100 = np.mean(rewards[-100:])
plt.bar(name, avg_last_100, alpha=0.7)
plt.ylabel('Average Reward (Last 100 Episodes)')
plt.title('Final Performance')
plt.xticks(rotation=15, ha="right")
plt.grid(axis="y", alpha=0.3)
plt.tight_layout()
plt.show()
print("=" * 70)
print("Tutorial Complete!")
print("Key Concepts Demonstrated:")
print("1. Epsilon-Greedy exploration")
print("2. UCB strategy")
print("3. MCTS-based planning")
print("=" * 70)We train all three agents in our grid world and visualize their learning progress and performance. We analyze how each strategy, Q-Learning, UCB, and MCTS, adapts to the environment over time. Finally, we compare results and gain insights into which exploration approach leads to faster, more reliable problem-solving.
In conclusion, we successfully implemented and compared three exploration-driven agents, each demonstrating a unique strategy for solving the same navigation challenge. We observe how epsilon-greedy enables gradual learning through randomness, UCB balances confidence with curiosity, and MCTS leverages simulated rollouts for foresight and planning. This exercise helps us appreciate how different exploration mechanisms influence convergence, adaptability, and efficiency in reinforcement learning.
